What a device record contains

A part number and a few headline numbers are not enough to size a converter. Every entry is stored as curves and waveforms — the form a loss model, a thermal solver, or an AI design agent can actually consume.

Double-pulse test waveform (raw record) Eon Eoff Itest VDC VGS ID VDS inductor charging (sets Itest) freewheel measurement pulse reverse recovery + Coss spike Lσ di/dt overshoot & ringing
Every device carries measured waveforms, not just a number. Full v/i captures at a stated DC-link voltage, gate resistance, loop inductance and junction temperature give integrated Eon and Eoff plus dv/dt, di/dt, overshoot and ringing frequency. A single datasheet energy figure does not transfer to your commutation loop — a waveform does.
Output characteristics 0 2 4 6 8 0 20 40 60 80 VDS (V) ID (A) VGS 18 V 16 V 14 V 12 V saturation · Tj = 25 °C
Source: digitised datasheet families plus curve-tracer measurements. Each record stores ID–VDS families at 25 / 125 / 175 °C, from which RDS(on), transconductance and de-saturation thresholds are extracted.
Junction capacitance vs. bias 0 200 400 600 800 1 pF 10 pF 100 pF 1 nF 10 nF VDS (V) C (log) Ciss Coss Crss Qoss / Eoss integrated to VDC
Why it is stored as a curve: integrating Coss(V) gives Qoss and Eoss, which set resonant commutation time, ZVS dead-time and whether zero-voltage switching closes at all. Crss sets dv/dt immunity and cross-talk margin.
Switching energy vs. current and Tj 0 10 20 30 40 0 200 400 600 800 ID (A) Esw (µJ) Eon Eoff Tj = 25 °C Tj = 150 °C
This is what a loss model consumes. Eon and Eoff are stored as a four-dimensional lookup over (I, VDC, Tj, Rg), so a mission-profile efficiency and junction-temperature iteration runs directly off the table instead of re-simulating every operating point.
Transient thermal impedance 1 µs 10 µs 100 µs 1 ms 10 ms 100 ms 0.001 0.01 0.1 1 pulse width tp Zth(j-c) (K/W) Rth(j-c) single pulse duty D = 0.2
Stored as a Foster/Cauer network, not a single number. Each package carries R–C ladder parameters that drop straight into an electro-thermal co-simulation, so junction-temperature swing ΔTj can be solved cycle by cycle over a mission profile — and ΔTj is exactly what a lifetime model needs.

Figures are illustrative of the stored data format. Background reading: double-pulse testing · static characterisation · gate charge & capacitance · transient thermal impedance.

Parameter coverage

Fields carried per device, with the test conditions attached. A value without its conditions is not data — so bias, temperature, gate drive and loop inductance travel with every number.

Static & package

  • VDS / VCES blocking voltage
  • RDS(on)(Tj) mΩ, normalised curve
  • ID–VDS families per VGS, per Tj
  • Vth, gfs with hysteresis where relevant
  • Body / freewheel diode VF, Qrr, trr
  • Package & footprint creepage, stray L, kelvin source

Dynamic

  • Ciss, Coss, Crss(V) full curve, not a point
  • Qg, Qgd, Qoss, Eoss integrated from curves
  • Eon, Eoff vs I, VDC, Tj, Rg
  • dv/dt, di/dt measured, per gate resistor
  • Overshoot & ringing with stated loop inductance
  • Raw DPT waveforms CSV, re-analysable

Thermal & reliability

  • Rth(j-c), Rth(j-a) K/W, stated boundary
  • Zth network Foster / Cauer R–C ladder
  • SOA & short-circuit withstand time, energy
  • Power-cycling data ΔTj vs cycles-to-fail
  • Derating rules voltage, current, temperature
  • Model links SPICE, PLECS, ANN surrogate

How it feeds a design

Shortlist under constraints

Filter by blocking voltage, current, package and cost, then rank by computed loss at your operating point rather than by datasheet headline figures.

Close the electro-thermal loop

Switching-energy tables and Zth networks solve together, so junction temperature, loss and derating converge instead of being assumed.

Feed the agent

The same records are exposed to AI-assisted design workflows, so a device choice comes back with the conditions and measurements that justify it.
